CMS631-Q470E,H420E

TOP ＞ CPUボード/モジュール ＞ CMS631-Q470E,H420E

CPUボード

CMS631-Q470E,H420E

CMS631-Q470E
CMS631-Q470E
CMS631-Q470E
CMS631-Q470E
CMS631-Q470E
CMS631-Q470E
CMS631-Q470E
CMS631-Q470E
CMS631-Q470E

10th Gen Intel® Core Processors

製品特長

  • ・2GB/4GB/8GB Memory onboard + one 204-pin SO-DIMM, Dual Channel DDR3L 1866MHz
  • ・Two independent displays: DP++/HDMI (auto-detection) + VGA/DP(opt.)
  • ・DP resolution up to 4096x2160 @ 60Hz
  • ・Multiple OS support: Win 7/Win 10/Linux
  • ・Rich I/O: max. 4 Intel GbE, 4 COM, 4 USB 3.1 Gen1, 2 USB 2.0
  • ・Extended operating temperature: -40 to 85°C

メーカーページへ

製品仕様

型番CMS631-Q470E,H420E
フォームファクターATX
サイズ305mm (12") x 244mm (9.6")
クラス
CPU10th Generation Intel® LGA 1200 Socket Processors, TDP support up to 125W Intel® Core™ i9-10900E (10 Cores, 20M Cache, up to 4.7 GHz); 65W Intel® Core™ i9-10900TE (10 Cores, 20M Cache, up to 4.5 GHz); 35W Intel® Core™ i7-10700E (8 Cores, 16M Cache, up to 4.5 GHz); 65W Intel® Core™ i7-10700TE (8 Cores, 16M Cache, up to 4.4 GHz); 35W Intel® Core™ i5-10500E (6 Cores, 12M Cache, up to 4.2 GHz); 65W Intel® Core™ i5-10500TE (6 Cores, 12M Cache, up to 3.7 GHz); 35W Intel® Core™ i3-10100E (4 Cores, 8M Cache, up to 3.8 GHz); 65W Intel® Core™ i3-10100TE (4 Cores, 8M Cache, up to 3.6 GHz); 35W Intel® Pentium® G6400E (2 Cores, 4M Cache, 3.8 GHz); 58W Intel® Celeron® G5900E (2 Cores, 2M Cache, 3.2 GHz); 58W Intel® Celeron® G5900TE (2 Cores, 2M Cache, 3.0 GHz); 35W
DRAMQ470E：Four 288-pin Non-ECC UDIMM up to 128GB H420E：Two 288-pin Non-ECC UDIMM up to 64GB Dual Channel DDR4 2400/2666/2933MHz
ChipsetIntel® Q470E/H420E Chipset
Ethernet1 x Intel® I211AT PCIe (10/100/1000Mbps) 1 x Intel® I219LM/I219V with iAMT12.0 (10/100/1000Mbps) (only Q470E Core i9/ i7/i5 supports iAMT) 2 x GbE (RJ-45)
I/O Interfaces1 x PCIe x16 (Gen 3) 1 x PCIe x4 (Gen 3) 5 x PCI Q470E：1 x M.2 2242/2260/2280 M key (PCIe Gen3 x4 NVMe/SATA/Intel® Optane Memory support) 1 x M.2 2242/2260/2280 M key (PCIe Gen3 x1/SATA as option, MOQ required) 1 x M.2 2230 E key (PCIe Gen3 x2/USB 2.0 as option, MOQ required) H420E：1 x M.2 2242/2260/2280 M key (SATA as option, MOQ required) 2 x GbE (RJ-45) 1 x RS-232/422/485 (RS-232 w/ power) (DB-9) Q470E：2 x USB 3.2 Gen2 2 x USB 3.2 Gen1 2 x USB 2.0 H420E：4 x USB 3.2 Gen1 2 x USB 2.0 1 x VGA 1 x DP++ 1 x HDMI 1 x Line-out 1 x Mic-in 1 x Line-in (opt., MOQ required)
Internal Connectors1 x RS-232/422/485 (RS-232 w/ power) (2.54mm pitch) 4 x RS-232 (2.54mm pitch) Q470E：2 x USB 3.2 Gen 1 4 x USB 2.0 (2.54mm pitch, colay vertical Type A, opt.: MOQ required) 1 x USB 2.0 vertical Type A H420E：2 x USB 3.2 Gen 1 2 x USB 2.0 (2.54mm pitch, colay vertical Type A, opt.: MOQ required) 1 x Front Audio Header 1 x S/PDIF Q470E：6 x SATA 3.0 (up to 6Gb/s) one SATA port share with M.2 M-key RAID 0/1/5/10 H420E：4 x SATA 3.0 (up to 6Gb/s) one SATA port share with M.2 M-key 1 x 16-bit DIO 1 x LPC Supports LPC EXT-RS232/RS485 module 1 x SMBus 1 x PS/2 (mini-DIN-6)
Expansion1 x PCIe x16 (Gen 3) 1 x PCIe x4 (Gen 3) 5 x PCI Q470E: 1 x M.2 2242/2260/2280 M key (PCIe Gen3 x4 NVMe/SATA/Intel® Optane Memory support) 1 x M.2 2242/2260/2280 M key (PCIe Gen3 x1/SATA as option, MOQ required) 1 x M.2 2230 E key (PCIe Gen3 x2/USB 2.0 as option, MOQ required) H420E: 1 x M.2 2242/2260/2280 M key (SATA as option, MOQ required)
Storage
音声Realtek ALC888
グラフィックスIntel® HD Gen 9 Graphics
ビデオインターフェース1 x VGA VGA: resolution up to 1920x1200 @ 60Hz 1 x DP++ DP++: resolution up to 4096x2160 @ 60Hz 1 x HDMI 1.4b HDMI: resolution up to 4096x2160 @ 24Hz
ボードコントローラ
内蔵BIOS機能AMI
セキュリティInfineon TPM2.0 (opt., MOQ required)
電源ATX
OSWindows 10 IoT Enterprise 64-bit Linux Ubuntu 20.04
温度Operating: -5 to 65°C Storage: -40 to 85°C
湿度Operating: 5 to 90% RH Storage: 5 to 90% RH
キャリアボード
CertificationCE, FCC Class B, RoHS, UKCA
