PR811-C622
CPUボード
PR811-C622
_w600.png)
_w600.png)
_w600.png)
Intel® 1st/2nd Xeon® Scalable Family
製品特長
- ・12 DDR4 RDIMM up to 384GB
- ・2 x 10GbE
- ・Single Display: VGA resolution up to 1920x1200 @ 60Hz
- ・Multiple expansion: 5 PCIe x16, 1 PCIe x8, 1 M.2 M key, 1 BMC Module slot for SEM2500/2510
- ・Rich I/O: 2 Intel 10GbE, 2 Intel GbE, 2 COM, 8 SATA 3.0, 6 USB 3.2 Gen1, 5 USB 2.0
製品仕様
| 型番 | PR811-C622 |
| フォームファクター | EATX |
| サイズ | 305mm (12") x 330mm (13") |
| クラス | |
| CPU | "1st Generation Intel® Xeon® Scalable Processor Family, LGA 3647 Socket: Intel® Xeon® Platinum 8160T (24 Cores, 27.5M Cache, up to 3.7 GHz); 150W Intel® Xeon® Gold 6138T (20 Cores, 27.5M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 6138 (20 Cores, 27.5M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 6130T (16 Cores, 22M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 6130 (16 Cores, 22M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 6126T (12 Cores, 19.25M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 6126 (12 Cores, 19.25M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 5120T (14 Cores, 19.25M Cache, up to 3.2 GHz); 105W Intel® Xeon® Gold 5119T (14 Cores, 19.25M Cache, up to 3.2 GHz); 85W Intel® Xeon® Gold 5118 (12 Cores, 16.5M Cache, up to 3.2 GHz); 105W Intel® Xeon® Silver 4116T (12 Cores, 16.5M Cache, up to 3.0 GHz); 85W Intel® Xeon® Silver 4116 (12 Cores, 16.5M Cache, up to 3.0 GHz); 85W Intel® Xeon® Silver 4114T (10 Cores, 13.75M Cache, up to 3.0 GHz); 85W Intel® Xeon® Silver 4110 (8 Cores, 11M Cache, up to 3.0 GHz); 85W Intel® Xeon® Silver 4109T (8 Cores, 11M Cache, up to 3.0 GHz); 70W Intel® Xeon® Bronze 3106 (8 Cores, 11M Cache, 1.7 GHz); 85W 2nd Generation Intel® Xeon® Scalable Processor Family, LGA 3647 Socket: Intel® Xeon® Gold 6252N (24 Cores, 35.75M Cache, up to 3.6 GHz); 150W Intel® Xeon® Gold 6238T (22 Cores, 30.25M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 6230T (20 Cores, 27.5M Cache, up to 3.9 GHz); 125W Intel® Xeon® Gold 6230N (20 Cores, 27.5M Cache, up to 3.5 GHz); 125W Intel® Xeon® Gold 6230 (20 Cores, 27.5M Cache, up to 3.9 GHz); 125W Intel® Xeon® Gold 6226 (12 Cores, 19.25M Cache, up to 3.7 GHz); 125W Intel® Xeon® Gold 5220T (18 Cores, 24.75M Cache, up to 3.9 GHz); 105W Intel® Xeon® Gold 5218T (16 Cores, 22M Cache, up to 3.8 GHz); 105W Intel® Xeon® Gold 5218N (16 Cores, 22M Cache, up to 3.7 GHz); 110W Intel® Xeon® Gold 5215 (10 Cores, 13.75M Cache, up to 3.4 GHz); 85W Intel® Xeon® Silver 4216 (16 Cores, 22M Cache, up to 3.2 GHz); 100W Intel® Xeon® Silver 4215 (8 Cores, 11M Cache, up to 3.5 GHz); 85W Intel® Xeon® Silver 4214 (12 Cores, 16.5M Cache, up to 3.2 GHz); 85W Intel® Xeon® Silver 4210 (10 Cores, 13.75M Cache, up to 3.2 GHz); 85W Intel® Xeon® Silver 4209 (8 Cores, 11M Cache, up to 3.2 GHz); 70W" |
| DRAM | "12 x 288-pin RDIMM up to 384GB Single Channel DDR4 2133/2400/2666/2933 MHZ (Support Intel DC Persistent Memory)" |
| Chipset | Intel® C622 Chipset |
| Ethernet | "2 x Intel® I210AT (10/100/1000Mbps) 1 x Intel® x557-AT2 (10GbE) 2 x GbE (RJ-45) 2 x 10 GbE x557-AT2 IPMI 2.0: 1 share w/ I210AT (opt.)" |
| I/O Interfaces | "5 x PCIe x16 (Gen 3) 1 x PCIe x8 (Gen 3) 1 x M.2 2280 M key (PCIe Gen3 x4 NVMe/SATA) 1 x BMC Module slot for SEM2500/2510 (IPMI) 2 x GbE (RJ-45) 2 x 10 GbE x557-AT2 IPMI 2.0: 1 share w/ I210AT (opt.) 1x RS-232 (DB-9) 4 x USB 3.1 Gen1 2 x USB 2.0 stack (opt.w/ RJ45 + USB2.0 stack) 1 x VGA (opt.)" |
| Internal Connectors | "1 x RS-232 2 x USB 3.1 Gen1 2 x USB 2.0 1 x USB 2.0 Vertical Type A 8 x SATA 3 (up to 6Gb/s) RAID 0/1/5/10 1 x SMBus" |
| Expansion | "5 x PCIe x16 (Gen 3) 1 x PCIe x8 (Gen 3) 1 x M.2 2280 M key (PCIe Gen3 x4 NVMe/SATA) 1 x BMC Module slot for SEM2500/2510" |
| Storage | |
| 音声 | ALC887 |
| グラフィックス | |
| ビデオインターフェース | 1 x VGA (opt.) VGA: resolution up to 1920x1200 @ 60Hz |
| ボードコントローラ | |
| 内蔵BIOS機能 | Insyde |
| セキュリティ | TPM 2.0 (opt.) |
| 電源 | ATX |
| OS | "Windows 10 IoT Enterprise LTSB RS5(64-bit) Windows Server 2019 Windows Server 2016 Linux" |
| 温度 | "Operating: 0 to 40°C Storage: -40 to 85°C" |
| 湿度 | "Operating: 5 to 90% RH Storage: 5 to 90% RH" |
| キャリアボード | |
| Certification | CE, FCC, RoHS, UKCA |
